Automatic Ring and Ball Sofening Point Apparatus for Resin or Asphalt

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Product Name：Automatic Ring and Ball Sofening Point Apparatus
  • Standard：ASTM D36
  • Features：Automatic
  • Measurement Range：32~160 Celsius
  • Measurement Resolution：0.01 Celsius
  • Heating Rate：5 Celsius Automatically After Three Minutes

Base Info

  • Model NO.：GD-2806G
  • Sample Quantity：2
  • PC Port：Yes
  • Printing：Yes
  • Transport Package：Wooden Case for Automatic Ring and Ball Sofening P
  • Trademark：GOLD
  • Origin：China
  • Production Capacity：100 Sets, Month

Description

13Measurement range:(1) Heating medium: distilled water 20 ºC~90ºC(softening point <=80 ºC)(2) Heating medium: glycerin 70ºC~160ºC(softening point >80 ºC)4Heating rate:it will be adjusted to 5.0±0.5 ºC/ min automatically after three minutes5Heating power:600 W6Stirrer:the electromagnetic stirring speed can be adjusted continuously, the stirring speed is (0~300) r/min7Cubage of beaker:1000 ml8Test result: LCD screen shows results and printer to print9Computer communication interface:RS-232C communication interface10Ambient temperature15ºC~35ºC11Relative humidity:≤85%12Total power consumption:<700 W13Dimension400mm×300mm×250mm
IV. Other Asphalt Testing Instrument:
Penetrometer series
Asphalt softening point tester series
Asphalt ductility tester series
GD-0620A Asphalt dynamic viscometer
GD-0613A Automatic breaking point apparatus
GD-0624 Asphalt tenacity tester
GD-0615 Petroleum asphalt wax content tester
GD-0610 85 Type asphalt rolling thin film oven
GD-0609 82 Type asphalt rolling thin film oven
GD-0621 Asphalt standard viscometer
GD-0623 Saybolt viscometer
GDE-1B Engler viscometer
GD-0709 Marshall stability tester
GD-0709A Marshall stability tester
GD-0752 Wet wheel abrasion tester
GD-0754 Cohesion tester
GD-0755 load wheel rolling tester
GD-F02-20 Automatic mixture blender
GD-0702 Marshall electric compactor
GD-0703 wheel-track modeling machine
GD-6307 Asphalt content tester
GD-0719 Automatic wheel-track tester(common type)
GD-0722 Centrifugal extractor
GD-0711A Bituminous mixtures theoretical maximum specific gravity tester
 V. Exhibition:
Automatic Ring and Ball Sofening Point Apparatus for Resin or Asphalt
VI. Certificate:
Automatic Ring and Ball Sofening Point Apparatus for Resin or Asphalt
