• Model NO.：HJ-66
• Accuracy Grade：No
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Touch Screen Controller
• Weight：40kg
• Power Source：AC220V
• Oil Cylinder Position：No
• Falling Ball Rebound Rate Accuracy：0.50%
• Test Sample Size：100 mm (Length) 100 mm (Width) X50 mm (Height)
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-66 Accuracy Grade No Load Way Electronic Load Loading Method Static Load Display Digital Control Touch Screen Controller Weight 40kg Power Source AC220V Oil Cylinder Position No Falling Ball Rebound Rate Accuracy 0.50% Test Sample Size 100 mm (Length) 100 mm (Width) X50 mm (Height) Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

The main function:
This machine is designed and manufactured in accordance with GB/T6670-2008, and conforms to ASTM D3574 and ISO8307 test standards. It also conforms to the test method of SES N3296 for urethane foam for Japanese automobile seat cushions. It is suitable for measuring the falling ball type of flexible polyurethane foam. Rebound performance. The instrument uses a steel ball with a given diameter and mass to freely fall on the foam sample at a specified height, and calculates the percentage of the ratio of the maximum height of the steel ball to the falling height of the steel ball, that is, the rebound rate. Rebound rate indicates the resilience performance of foam.


Steel ball falling distance Steel ball diameter	460±0.5%mm (national standard) 500±0.5%mm  (American standard) 16±0.05 mm
Falling Ball Rebound Rate Accuracy	0.50%
Test sample size	100 mm (length) × 100 mm (width) × 50 mm (height)  automatically calculates the average spring rate
Main configuration	A set of host (including release mechanism, height adjustment mechanism) a set of control box (LCD touch screen control)
design standards	GBT 6670-200

      FAQ

1. Do you offer after-sales service? How can I ask for that? And how about the warranty?
   Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

   2.. What's the delivery term?
   At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
