• Model NO.：JB-300B,500B,800B
• Loading Method：Static Load
• Display：Needle
• Control：Manual Control
• Weight：500-1000Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Delivery Time：3 Days After Get Tt Payment
• Impact Speed：5.2m,S
• Transport Package：Standard Export Packing
• Specification：2200× 650× 1960mm
• Trademark：HST
• Origin：China
• HS Code：9031809090
• Production Capacity：900 Sets Per Month

JB-300BJB-500BJB-800Bimpact energy150/300J250/500J500/800JThe distance between the
pendulum shaft and impact  point750mm850mm800mmImpact speed5.2m/s5.4 m/s5.9m/sPre-rising angle of the pendulum150°Specimen bearer span40+0.2mmRound angle of the jawR1-1.5mmRound angle of impact edgeR2-2.5mm,R8±0.05mmAngle accuracy0.1°Standard specimen dimension10mm×10(7.5/5)mm×55mmPower supply3phs, 380V, 50Hz Or 220V,60HzDimensions (mm)2124 x 600 x 13402200 ×650 ×19602450 x 1200 x 2455
 Net Weight (kg)45065023004. Features:
4.1 The principle machine of the testing machine has single supporting column structure, cantilever type pendulum hanging mode; the pendulum body is U-shaped
4.2 The impact cutter is installed and fixed by screws and is convenient and easy to be replaced;
4.3 Safety guard pin is arranged on the principle machine which is also provided with safety guard net;
5. Configurations:
5.1 Main unit----------1 set
5.2 Pendulum

JB-300B	JB-500B	JB-800B
150J/300J--2 pcs	250J/500J--2 pcs	500J/800J--2 pcs


5.3 Span specimen plate (L = 40mm)----1 pc
5.5 Specimen centering plate (L = 40mm)(U, V)----1 pc
5.6 Stripping attachment----1 pc
5.7 Internal hexagonal wrench (S=12mm)---1 pc
5.9 Anchor bolts (M16x300mm)---4 pcs
5.10 Impact testing security guards----1 pc
