ASTM D2063 Automatic Torque Tester
Pubtester Instruments Co., Ltd.- Warranty：12 Months
- Display：Digital
- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC220V
- Load Cell Capacity：5 Nm(Standard) 20nm, 40nm(Optional)
Base Info
- Model NO.：DTT-02
- Accuracy：0.5% Fs
- Resolution：0.001nm
- Bottle Height：20 mm~400 mm
- Trademark：Pubtester
- Origin：China
Description
Extended ApplicationApplication & Removal Torque of Screw Nut Open and lock force test of the screws Vacuum Flask and Vacuum Cup Open and lock force test of the caps of vacuum flasks and vacuum cups
Technical SpecificationsLoad Cell Capacity5 N·m(Standard) 20N·m, 40N·m (Optional) Accuracy 0.5% FS Resolution 0.001N·m Body Clamp Range Φ5 mm~Φ170 mm Cap Clamp Range Φ10 mm~Φ80 mm Bottle Height 20 mm~400 mm Maximum Removal/Application Torque 2 Nm (customization) Specimen Clamping and Turning Way Pneumatic Gas Supply Air (Not in supply scope) Gas Supply Pressure 0.7 Mpa (101.5psi) Statistical Analysis Allowance 0 ~ 50000 Instrument Dimension 570 mm (L) × 375mm (W) × 1200mm (H) Power Supply AC 220V 50Hz /120V 60Hz Net Weight 38 kg
Standards
ASTM D2063, ASTM D3198, ASTM D3474, GB/T 17876, BB/T 0025, BB/T 0034
Configuration
Standard Configuration:Instrument, Micro-printer, Auto Testing System
Optional Parts: Air Compressor
Note: 1.The gas supply port of the instrument is Φ4 mm PU Tubing;
2. Customers will need to prepare for gas supply.
