Dielectric Withstand Voltage Test 100kv Transformer Oil Portable Bdv Oil Tester

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Transport Package：Standard Wooden Case
  • Trademark：GOLD
  • Origin：China

Base Info

  • Production Capacity：500 Sets,Month

Description

PARAMETERGDYJ-502StandardsIEC60156/IS6792/BS5874, ASTMD877, ASTMD1816Output voltageAC 0V~100KVRate of voltage rise0.5kv/s±5%, 2kv/s±5%, 3kv/s±5%,5kv/s±5%Measurement Precision3%RDG+0.3%FSTest times setting9Temperature measurementNoMaximum storage capacity100 groupsDisplayLCD screenPrinterYesOil Vessle1Power supplyAC 220V±10% 50Hz/60HzOperating Temperature0-50°CRelative Humidity≤80%RHDimension620*430*330mmWeight41kg

Functions:

  • Breakdown test of user-defined;
  • Proof test;
  • IEC60156/IS6792/BS5874 test;
  • ASTM D1816 standard test;
  • ASTM D877 standard test;
  • 5 minutes standard test;
  • Manual test;
  • Calibration interface for customers;
  • Uploading data to PC and making word report automatically;
  • Result print.

Features:

  • LCD screen can display test procedure and test result;
  • All the human interaction operations complete by the rotating mouse;
  • It is very easy for customers to measure the breakdown voltage of all kinds of oil;
  • You can print the test result by the micro printer internal the tester;
  • Meanwhile, you can upload the test data to PC from RS232 for data analyzing;
  • The special circuit design makes the tester has a good performance at stability and anti-noise.

Product Show:
Dielectric Withstand Voltage Test 100kv Transformer Oil Portable Bdv Oil Tester
