• Model NO.：GW-001C
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V,110V,380V
• Oil Cylinder Position：Electric Control
• Flex Angle：22.5 Degree
• Pieces to Be Test：4 Pieces
• Flexing Speed：100 C.P.M
• Counter：6 Digits, Number Shows
• Motor：1,8 HP
• Power：AC220V, 50Hz,60Hz
• Transport Package：Standard Export Safety Packing
• Specification：83*40*33cm
• Trademark：Great Win
• Origin：China
• HS Code：9024800000
• Production Capacity：500pieces,Year

Basic Info.

Model NO. GW-001C Loading Method Dynamic Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V/110V/380V Oil Cylinder Position Electric Control Flex Angle 22.5 Degree Pieces to Be Test 4 Pieces Flexing Speed 100 C.P.M Counter 6 Digits, Number Shows Motor 1/8 HP Power AC220V, 50Hz/60Hz Transport Package Standard Export Safety Packing Specification 83*40*33cm Trademark Great Win Origin China HS Code 9024800000 Production Capacity 500pieces/Year

Product Description

Bally leather flexing testing machine/equipment(GW-001)

Brief introduction:
Place the specimen in position and bend it repeatedly until it breaks. Record the bending times. This device is suitable to test thin leather products for vamp, dress cloth and bags.

Technical Specifications:

Model	GW-001 Bally leather flexing testing machine
Bending degree:	22.5°
Speed:	100±3cpm
Flexing grips:	3 sets
Power:	AC220V
Counter:	LCD(0~99999999)
Dimension:	790*420*350mm
Weight:	5KGS
Attached accessories:	1PCS Did cut 70*45cm



Standard for:
BS-3144, JIS-K6545, GB/T20991-2007, SATRA TM55


Attached accessories:
1PCS Did cut 70*45cm
What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.

What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.

What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.

What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
