DH-300C Water Cooling Plastic Testing Machine, Determination Of Heat Deflection Temperature Vicat Softening Point Apparatus

DongGuan HongTuo Instruments Co., Ltd.
  • Type:Softening Point Device
  • Display:Digital
  • Usage:Plastic Testing Machine
  • Heating Medium:Methyl Silicone Oil
  • Testing Before Delivery:Yes
  • After-sale Customer Service:Yes

Base Info

  • Model NO.:DH-300C
  • Cooling Method:Water Cooling
  • Transport Package:Standard Exporting Wooden Package
  • Trademark:DahoMeter
  • Origin:Dongguan, China
  • Production Capacity:300 Sets,Month

Description

Basic Info.

Model NO. DH-300C Cooling Method Water Cooling Transport Package Standard Exporting Wooden Package Trademark DahoMeter Origin Dongguan, China Production Capacity 300 Sets/Month

Product Description

DH-300C Water Cooling Plastic Testing Machine, Determination Of Heat Deflection Temperature Vicat Softening Point Apparatus





Application



Suitable for measuring the HDT and vicat softening point temperature of plastic,hard rubber,nylon,electrical insulating material,macro fiber reinforced composite material,high strength thermoset laminate material material.etc.



Controled by PC;detected deformation by displacement sensor;real-time curve drawing;processing measuring data directly on PC;measuring data can be output to office software and be eidited.



Standards


GB/T 1633,GB/T 1634,GB/T 8802,ISO 2507,ISO 75,ISO 306,ASTMD 1525,ASTMD 648



Parameter



  • Controlling temperature range:room temperature to 300ºC
  • Maximum temperature error:±0.5ºC
  • Rate of temperature increasing:50ºC/h,120ºC/h
  • Temperature measuring point:1
  • Deformation measuring range:-0.1mm to 1.1mm
  • Maxinum deformation error:±0.01mm
  • Medium:methylsilicone oil
  • Specimen supporting space:64mm;100mm
  • Cooling method:natural cooling if more than 150ºC;water cooling or natural cooling if less than 150ºC
  • Function of ceiling temperature protection
  • Specimen holder:3 pieces
  • Controlling method:singlechip and PC distribute control system
  • Dimension:880mm*580mm*1400mm
  • Space required:1m for front and back side;0.6m for left and right side
  • Power supply:4500VA 220VAC 50HZ


Certification
DH-300C Water Cooling Plastic Testing Machine, Determination Of Heat Deflection Temperature Vicat Softening Point Apparatus


Related Products



Solid series:DH-300,DH-600,DH-900,DA-300M,DA-600M,DA-900M,DA-1200M,DE-120M,DE-600M,DH-300M,DH-120M,DH-3000M,DH-120N
