• Model NO.：16-T0012,C
• HS Code：90248000
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. 16-T0012/C HS Code 90248000 Production Capacity 100 Sets/Month

Product Description

LIGHT-WEIGHT MANUAL DYNAMIC PENETROMETERS
DYNAMIC CONE PENETROMETER (DCP) 16-T0012/C 8 kg hammer, 57.5 cm. fall
Standard: ASTM D 6951-03

Model 16-T0012/C FEATURES:
• Portable, hand-operated equipment.
• To obtain a direct evaluation of the "in-situ" strength properties of road pavement layers: the DCP has been correlated with CBR (California Bearing Ratio - Kleyn 1975).
• Field calibration of a portable dynamic cone penetrometer was made to determine a penetration resistance relationship with the standard penetration resistance.
• The penetrometer has been found useful in the inspection of footing foundations and for light field exploration where the standard penetration range of limits is generally known
• One year warrantee against any manufacturing defects.




COMPRISES:
16-T0012/C1 Sliding hammer (steel made) weighing 8 kg
16-T0012/C2 Impact anvil driving rod and clip, falling 575 mm
16-T0012/C3 Steel rod, diameter 16 mm, up to a depth of 800 mm below the surface
16-T0012/C4 N° 3 threaded end cones in tempered steel,20 mm diameter, 60° cone angle
16-T0012/C5 Bearing plate and measuring rod with adjustable scale (graduated in mm)
16-T0012/C6 Alloy aluminum carrying case
Dimensions: 1080x310x150mm
Weight: 22kgs
ACCESSORIES AND SPARE PARTS: (need to be ordered seperately)
16-T0012/C7 Extension rods: 400 mm, dia. 16mm
