GDCR1000D Non-contact Phase Sequence Tester High Voltage Sequence Meter

HV Hipot Electric Co., Ltd.
  • Type：Universal Testing Machine
  • Weight：0-100Kg
  • Power Source：DC 3V 2 section alkaline dry cell (LR6)
  • Oil Cylinder Position：no
  • Function：Phase check, live line check, breakpoint location
  • Live range：AC 70~1000V, 45~65Hz

Base Info

  • Model NO.：GDCR1000D
  • Dimension：L 70mm* H 75mm* W30mm
  • Clamp wire length：0.6m
  • Working condition：-10ºC~55ºC;<80%rh
  • Storage condition：-20ºC~60ºC;<90%rh
  • Measurement max. voltage：AC 1000V
  • Dielectric strength：5.4kV RMS
  • Max. rated power：300mVA
  • Standards：EN61010-1:2001, EN61010-031:2002
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • Production Capacity：3000PCS,Year

Description

Model

Test wire outer diameter

GDCR1000C

ø1.6mm~ø16mm

GDCR1000D

ø10mm~ø40mm







Specification

Function

Phase check(positive phase, reverse phase, missing phase), live line check, breakpoint location , line maintenance

Power supply

DC 3V 2 section alkaline dry cell (LR6), continuous use time of about 70 hours

Live range

AC 70~1000V, 45~65Hz (sine wave continuous input)

Test wire size

Outer diameter ø1.6mm~ø16mm or ø10mm~ø40mm(optional)





LED display

[positive phase] 4 phase detection lights turn on clockwise in turn;

[reverse phase] 4 phase detection lights turn on clockwise sequentially.

[live line] L1, L2 and L3 lights turn on within the range of voltage setting;

[missing phase] L1 or L2 or L3 lights are not on.

[open circuit] The L1 or L2 or L3 lights are not on.

Buzzing

[positive phase] instrument emits intermittent short buzz;

[reverse phase] The instrument emits continuous long sounds.

Battery Indication

POWER indicator lights up after power on; LOW BATTERY lights up when power is insufficient

Magnetism

There are four magnets attached to the back of the instrument, which are attached to the distribution box and can withstand 800g quality.

Shut off

After about 5 minutes, the instrument shuts down automatically.

Dimension

L 70mm* H 75mm* W30mm

Clamp wire length

0.6m

Weight

About 200g (include battery)

Working condition

-10ºC~55ºC;<80%rh

Storage condition

-20ºC~60ºC;<90%rh

Measurement max. voltage

AC 1000V

Dielectric strength

5.4kV rms

Max. rated power

300mVA

Standards

EN61010-1:2001, EN61010-031:2002, pollution class 2, CAT III (600V), transient overvoltage 6000V
