GDYD-137D AC Hipot Test Set 130kV Bucket Test Bucket Truck Test Equipment
HV Hipot Electric Co., Ltd.- After-sales Service:Yes
- Warranty:1 year
- Type:Universal Testing Machine
- Accuracy Grade:3
- Load Way:Electronic Load
- Loading Method:Dynamic Load
Base Info
- Model NO.:GDYD-137D
- Display:Digital
- Control:Manual Control
- Weight:100-500Kg
- Power Source:AC220V
- Transport Package:Standard Export Plywood Case
- Specification:ISO
- Trademark:HV HIPOT
- Origin:Wuhan, China
Description
Basic Info.
Model NO. GDYD-137D Display Digital Control Manual Control Weight 100-500Kg Power Source AC220V Transport Package Standard Export Plywood Case Specification ISO Trademark HV HIPOT Origin Wuhan, ChinaProduct Description
GDYD-137D AC Hipot Test Set 130kV Bucket Test Bucket Truck Test EquipmentI. General information
GDYD series AC hipot test set is composed of manual control unit and AC gas testing transformer (HV unit) which output AC voltage smoothly. It is suitable for testing boom truck.
II. Features
- Digital display meters mounted on the panel.
- Monitoring HV side voltage, HV side current, LV side current and indicator of zero, power, working start, timing.
- Over-current protection, zero-starting protection, sound, and light alarm.
- With new type time relay, time range is wider (1S ~ 99H).
- Using the latest current relay, more accurate and reliable.
- Light weight, small size, easy to move.
III. Specifications
- Control unit specifications
- Power: AC220V, 50Hz two phase
- Capacity: 7kVA
- Output voltage: AC 0-250V
- Rated output current: 35A
- HV voltmeter range: 0-140kV, tap voltage range: 0-36kV
- HV ammeter range: 0-50mA
- Timing range:1s-99h
- Weight: approx. 39kg
- Dimension: 490mm (L)* 370mm (W)* 510mm (H)
B. Testing transformer (HV unit) specifications
- Input voltage: 0-200V
- Input current: AC 0-35A
- Output voltage: AC 0-140kV, 0-36kV
- Output current: AC 50mA, DC194mA
- Capacity: 7kVA
- HV side/LV side turns ratio: 700:1
- Measuring voltage: AC 0-100V
- No-load current: <10%
- Impedance voltage: <10%
- Weight: approx. 125kg
- Dimension: 550mm(L)*630mm(W)*1350mm(H)
C. Working conditions
- Working place: No gas, steam, chemical dust, and explosive and corrosive medium which will influence insulation.
- Environment temperature: -20-50ºC
- Environment humidity: ≤85% RH (no condensing)
