High Quality Single and Double Bitumen Wheel Rutting Test Machine
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Specimen Size：300X300X50mm or Other Require Dimension
- Ruuber Hardness：84± 4 International Standard
- Test Wheel Moving Distance：230mm+,- 10mm
- Deformation Measurement Precision：0.3%
- Transport Package：Wooden Box
- Specification：En 12697-22
Base Info
- Model NO.：HYCZ-1
- Trademark：C-Tech
- Origin：China
- HS Code：90248000
- Production Capacity：1000 PCS,Year
Description
Basic Info.
Model NO. HYCZ-1 Trademark C-Tech Origin China HS Code 90248000 Production Capacity 1000 PCS/YearProduct Description
Bitumen Wheel Rutting Test MachineSpecifications
Wheel tracking machine for rutting ability of asphalt & asphalt-concrete materials in high temperature.
Max. Temperature: 80 degree
1. Application: This tester is used to test the high-temperature wheel rutting ability of asphalt mixture for the high-temperature stability performance of related mixing proportion design.
2. Characteristic: This tester is made with advanced single-chip microcomputer controlling technology, machine finishing technology and related new developping application software.
3. Main technical parameter:
Specimen size: 300x300x50mm or other require dimension
Working method: Crank connecting rod driven test wheel movement
Ruuber hardness: 84± 4 international standard
Test wheel moving distance: 230mm± 10mm
Load cycles: 21± 1 cycles/min, or 26.5± 1 cycles/min
Loading device: The contact pressure is 0.7± 0.05Mpa when the temperature is 60oC, total loading is around 78kg and adjustable
Deformation measurement precision: 0.3%
Heating power: 3KW
Temperature control precision: 0.5oC
Working temperature: 0~80oC humity≤ 90%, haven't corrosive and flammable gas
Driving motor power: 0.75KW
Weight: 500KG
