• Max Stroke of Z：350mm
• Speed of Punch：60,100 Hpm
• Positioning Repeatability：0.20 mm,M
• Max. Punch Diameter：32mm
• Transport Package：Standard Packing
• Specification：7500*2980mm
• Trademark：STI
• Origin：Shandong
• Production Capacity：100 Sets ,Month

Basic Info.

Max Stroke of Z 350mm Speed of Punch 60/100 Hpm Positioning Repeatability 0.20 mm/M Max. Punch Diameter 32mm Transport Package Standard Packing Specification 7500*2980mm Trademark STI Origin Shandong Production Capacity 100 Sets /Month

Product Description

CNC Busbar Punching Machine

1.GJCNC-BP series CNC Busbar Punching Machine is a professional high efficient and high accurate busbar processing machinery controlled by computer.
-The punching dies,shearing die,embossing die are put at the tooling library.
-The machine can finish hole punching (round hole,oblong hole etc), embossing,shearing,grooving,cutting filleted corner etc.
-The machine can realize auto rotating of clampas for long busbar,human intervention is not needed. Thefininshed workpiece will be automatically delivered via the conceyor.
-This series machine can match with CNC bender and forn busbar processing production line.

2.GJ3D / programming software
The special aided design software of busbar processing (GJ3D) is connected with the machine and auto program is realized. User operates the software,it is convenient and fast .The software can calculate the hole punching position after bending is extended ,automatically form machine code and avoid complicated manual coding of machine language. The softwage can demonstrate the whole process of busbar punching,shearing and bending and prevent effecively the material waste because of input fault.Our company took the lead and applies the 3D graphic technique into the busbar processing industry,which is a great contribution to the industry and advanced technology is wordclass level.

3.Touch Screen
Human-computer interface,the operation is simple and can demonstrate real-time the operation atatus of the program,the sceen can show the alarm information of the machine; it can set the basic die parameters and control the machine operation.

4.Primary,Secondary Clamps
The machine adopts primary,secondary clamps structure,which can guarantee effectively the straightness of the workpiece to increase the processing accuracy;
The clamps adopt hydraulic driving technique,the structure is compact,the work is stable,no noise and no need of gas.

5.High Speed Operation System
High accurate ball screw transmission,coordinated with high accurate straight guide, high precision,fast effective,long service time and no noise.

6.Fast Conveyor
Stainless steel conveyor can guarantee no wear of the workpiece,long service reliability.
