Impulse Current Generator
Sansion Power Electric Co., Ltd.- Type：Impact Testing Machine
- Maxcapacity：>1000KN
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：SXCL
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC380V
- Output Waveform：1,<20us, 4<10us, 8,20us, 10,350us, 18,40us and 10
- Task：Generate
- Structure：Combination
- Mathematical Model：Linear
- Signal：Continuous
- Function：Automatic Control
- Certification：ISO: 9001, IEC, SGS
- Condition：New
- Customized：Customized
- Transport Package：Plywood Case
- Trademark：Sansion Power
- Origin：Wuhan, China
- Production Capacity：100 Sets, Year
Description
Output Waveform
4/10μS
8/20μS
10/350μS
10/1000μS
1000μS
2000μS
Max.KA
100
5,10,20,40
60,80,100
10,20,50,100
0.5,1,2,3
5,10
0.2,0.5,1
0.5,1,2,3
Applicable Test Object
A
A V G
A V G
A V G
A V
A V
A. Arrestor & Units
V. Voltage Surge Protector
G. Discharge Tube
Note: The over shape and structure of impulse current generator is different according to its different waveform, max. current, functions combination, test objects and etc. It could be designed as table type (small size), cabinet type(middle size) or split system (large scale).
More details please contact Mrs. Ying Ying by email for further information.
Please contact Sansion Power Electric for details information, we can select correctly designed products for you.
