• Model NO.：SGW-630
• The Minimum Value：0.1ºC
• Repeatability of Indication：When The Heating Rate Is 1.0ºC,Min,0.3ºC
• Linear Heating Rate Error：±10%
• Processing Power：3
• Capillary Size：Outside Diameterφ1.4mm
• Inside Diameter：φ1.0mm
• The Sample Height：3mm
• Data Storage：16g
• Transport Package：Standard Export Package
• Specification：Automatic lmage
• Trademark：WEST TUNE
• Origin：China
• HS Code：9031809090
• Production Capacity：1000units,Year

Basic Info.

Model NO. SGW-630 The Minimum Value 0.1ºC Repeatability of Indication When The Heating Rate Is 1.0ºC/Min,0.3ºC Linear Heating Rate Error ±10% Processing Power 3 Capillary Size Outside Diameterφ1.4mm Inside Diameter φ1.0mm The Sample Height 3mm Data Storage 16g Transport Package Standard Export Package Specification Automatic lmage Trademark WEST TUNE Origin China HS Code 9031809090 Production Capacity 1000units/Year

Product Description

SGW-650/SGW-630 lmage Melting-Point Apparatu

The image melting point apparatus is mainly used for measuring the melting point of drugs, dyes, fragrances and other organic compounds crystals. With LCD screen, the image of whole process of melting the material can be observed,while the instrument provides the melting parameters of the material. The instrument applies a high-resolution camera or photo-detection system to automatically/manually detect the melting point, software and hardware. Its capable of monitoring the entire process of melting material, and while the image is being played back, the whole process of melting can be observed, and test data can be generated. The instrument is equipped with windows 7 operating system.



FeaturesIt adopts a high-resolution digital camera, which is automatically detected by image processing and analysis, and has a playback function.
Simultaneous measurement of three capillaries (SGW®-630).
Built-in WINDOWS operating system, simple, convenient, intuitive and clear, and can be connected to the printer.
The temperature control system uses platinum resistance with high linearity as the detection element, which improves the accuracy and reliability of the melting point.
The instrument has two functions: automatic measurement and manual visual measurement, allowing you to clearly grasp the continuous change process of the sample and mutually verify the accuracy of automatic testing and visual measurement.
The instrument can measure dark samples or opaque samples, has a multi-point calibration function, and test data can be saved, exported, and uploaded.
It complies with the relevant requirements of GMP, GLP and FDA/21CFR 11, and includes functions such as user hierarchical management, electronic signature, password management, network transmission, data protection and traceability.
 Specifications

Parameters/Model	SGW-650	SGW-630
Measurement range of melting point	Room temperature - 400ºC	Room temperature ~ 400ºC
Measurement methods	Automatic, visual (playback monitoring)	Automatic, visual (playback monitoring)
Pre-stored measurement methods	300	300
Password management	level 4	level 4
User Management	50	50
Electronic signature	Yes	Yes
Minimum value of temperature display	0.1ºC	0.18ºC
Linear heating rate	0.2ºC/min 0.5ºC/min 1ºC/min 1.5ºC/min 2ºC/min 3ºC/min 4ºC/min 5ºC/min	0.2ºC/min 0.5ºC/min 1ºC/min 1.5ºC/min 2ºC/min 3ºC/min 4ºC/min 5ºC/min
Accuracy	≤200ºC±0.5ºC,>200ºC±0.8ºC	≤200ºC±0.5ºC, >200ºC±0.8ºC
Repeatability	0.3ºC(heating rate: 1.0°ºC/min)	0.3ºC(heating rate: 1.0ºC/min)
Linear heating rate error	Not greater than 10% of the nominal value	Not greater than 10% of the nominal value
Number of capillary	5	3
Capillary dimensions	Outer diameter: φ1.4mm; Inner diameter: φ1.0mm;Height:90mm	Outer diameter: φ1.4mm lnner diameter: φ1.0mm;Height: 90mm
Height of sample	3mm	3mm
GMP regulations	Qualified	Qualified
Data storage	16G	16G
Display	8 inches touch screen	8 inches touch screen
Interface	USB/Keyboard/Mouse/Universal Printer/VGA/Ethernet/Optical wireless card for wireless internet access	USB/Keyboard/Mouse/Universal Printer/VGA/Ethernet/Optical wireless card for wireless internet access
Dimension	500mm x 470mm x 380mm	500mm x 470mm x 380mm
Weight	17kg	17kg
