Paper Ring Crush Strength Test Machine

Dongguan Hong Tu Instrument Co., Ltd.
  • Type：Paper Ring Crush Strength Test Machine
  • Accuracy Grade：0.5
  • Load Way：Mechanical Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Manual Control

Base Info

  • Model NO.：HT-A513-1
  • Weight：0-100Kg
  • Power Source：AC220V
  • Materials：Stainless Steel or Aluminum Alloy
  • Capacity (Optional)：10, 20, 50, 100, 200 Kg
  • Resolution：1,100,000
  • Precision：< 0.5%
  • Operation Mode：Computer
  • Display Mode：LCD
  • Compressed Space：500 Mm
  • Ring Crush Sample：152*12.7 Mm
  • Transport Package：Stronger Wooden Case
  • Trademark：HOTOTECH
  • Origin：Dongguan
  • Production Capacity：100 Sets Per Month

Description


Capacity  (Optional)10, 20, 50, 100, 200 kgResolution1/100,000Precision< 0.5%Operation ModeComputerDisplay ModeLCDPlaten100×100 mm or depending on the diameter of the flat crush sampleCompressed Space500 mmPlaten Parallelism± 0.05 mmRing Crush Sample152×12.7 mmEdge Crush Sample25×100 mmTest Speed12.7 mm/minDimension (L×W×H)790×510×1060 mmWeight Approx. 51 kgPower AC220V, 1.5A
