• Model NO.：EVT
• Table Size：500*600(Mm)
• Test Program Number：No Limit
• Test Time：No Limit
• Vibration Dimensions：W625*D525*H690mm
• Transport Package：Strong Plywood Case for Long Journey Delivery
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

Basic Info.

Model NO. EVT Table Size 500*600(Mm) Test Program Number No Limit Test Time No Limit Vibration Dimensions W625*D525*H690mm Transport Package Strong Plywood Case for Long Journey Delivery Specification Standard and Customized Trademark KOMEG Origin Dongguan, China HS Code 90321000 Production Capacity 1000 Sets/Year

Product Description

Revolutionary invention! Electromagnetic Vibration Test Machine
Decrease your Cost Dramatically and increase your profit greatly!

Why should you choose KOMEG?
1. Dedicate touch and excellent user experience;
2. Unique and compact design, top grade appearance, stable performance and easy operation;
3. Can simulate a wide range of temperature and humidity environments;
4. Capable of testing large components, assemblies, and finished products;
5. Customized sizes and comfigurations available;
6. One year warranty

The Electromagnetic Vibration Test Machine apply to military, aviation, aerospace, electronic, mechanical and electrical, optical, communications, computers, motor vehicles, toys, packaging and other industries.
Used for detecting early failure, simulate real working conditions, inspect products structure performance

Equipment summary:
The Multi-Frequency Machanical Vibration Testing Chamber is used to do shock testing for mechanical and electrical and electronic components, communications, equipment, computers and motor vehicles parts, it is also used to inspect the durability of products or effectiveness of the transport. By that testing manufacturer can identify the product quality, vibration tolerated performance.

We Supply the following products:
Programmable Constant Temperature and Humidity Test Chamber
3-zone/ 2-zone Thermal Shock Chamber
Walk-in Constant Temp. And Humidity Chamber
Rapid Temp. Change Chamber
Precise Drying Test Chamber
Temperature/ humidity/ vibration three integrated Chamber
Precise Drying Chamber
Vacuum oven/ no oxidation oven
Air Exchange Type Aging Oven
Burn-in Room
Salt spray Chamber
Two wing Drop Tester

Vibration Testing Machine
Specifications
1. Humidity vibration test chamber;
2. High accurate value;
3. Siemens PLC controller;
4. Colour LED display

Use four points synchro reverse direction, good uniformity for the test table
Frequency is adjustable free, can meet different test specimen requirements
Double Chinese and English windows standard control interface

Each product have to experience is to be transported from one place to another.
How do you know your products can survive this vabration without?

Vibration test machine is widely applicable to the defense, aerospace, communications, electronics, automobiles, household appliances and other industries.
Temperature and humidity test chamber matched with appropriate vibration test bench to meet with respective corresponding

The following is the technical parameter:

Model	VS-5060
Frequency range	10-80Hz
Frequency accuracy	±0.05Hz
Acceleration range	0 ~ 11G(peak)
Maximum Payload	80kg
Test Mode	Fix ; Sweep ; Multi-random
Displacement range	0 ~ 2.8mm p-p, adjustable
Table size	500*600mm
Test program number	No limit
Test time	No limit
Power	AC220V 1Φ 50Hz 5A
Vibrator dimensions	W625*D525*H690mm
