• Model NO.：HZ-2813
• Display：Digital
• Weight：0-100Kg
• Power Source：AC220V
• Input Power：220V±10% 50Hz±10%
• Atmospheric Pressure：86~106kpa ºC
• Temperature：-10~40ºC
• Humidity：<80%Rh
• Insulation Resistance：>2mΩ
• Current：Range: 20.00A, Resolution: 0.01A
• Output Power：DC30~250V Digitally Adjustable ,20A (Instantaneous
• MOQ：1
• Keyword：Circuit Breaker Analyzer
• Transport Package：Wooden Box with Foam Inside
• Specification：CE,ISO,IEC
• Trademark：HuaZheng
• Origin：Hebei, China
• HS Code：9031809090
• Production Capacity：500,Month

Basic Info.

Model NO. HZ-2813 Display Digital Weight 0-100Kg Power Source AC220V Input Power 220V±10% 50Hz±10% Atmospheric Pressure 86~106kpa ºC Temperature -10~40ºC Humidity <80%Rh Insulation Resistance >2mΩ Current Range: 20.00A, Resolution: 0.01A Output Power DC30~250V Digitally Adjustable /20A (Instantaneous MOQ 1 Keyword Circuit Breaker Analyzer Transport Package Wooden Box with Foam Inside Specification CE/ISO/IEC Trademark HuaZheng Origin Hebei, China HS Code 9031809090 Production Capacity 500/Month

Product Description

Portable High and Low Voltage Power-on Circuit Breaker Test Console  I.OverviewHZ2813 type high and low voltage switchgear power-on test bench is used by high- and low-voltage switchgear manufacturers to conduct various power-on tests before and after leaving the factory. It can provide a variety of AC and DC power supplies to facilitate the detection of switch cabinets and improve work efficiency.

II.Technical parameters
Input power: three-phase four-wire AC380V
Output voltage and current:
1. Three-phase AC 100V output(fixed value)                         1 set
2. Three-phase AC 0~10A output(100V,adjustable value)         1 set
3. Single-phase 24V,36V,110V,220V DC fixed output               1 set
4. AC operating voltage output  AC  0 ~ 450V,220V,current is less than 10A  1 set
5. DC operating voltage output DC  0 - 260V                          1 set
6. Single-phase AC220V output(fixed value, socket type)             2 sets
7. Three-phase AC380V output,220V output(fixed value, terminal)    1 set
8. Closing control contact, opening control contact                  Each 1 set
9.With universal wheel, digital display meter display, digital display meter accuracy is 0.5, silver gray housing
10.Working environment: 0~40ºC;ambient temperature≤85%

III. Company Information

HuaZheng Electric Manufacturing (Baoding) Co., Ltd is the supplier of the State Grid in China. It means we are the supplier of the Chinese Government. And our products spread throughout the whole China.

What's more, our customers come from different countries like America, England, Bulgaria, Brazil, Chile, Malaysia, Vietnam and so on.

Our main products are Digital Multimeter, Insulation Oil Tester, Cable Fault Locator, Power Quality Analyzer, High Voltage Generator, High Voltage Capacitor, Testing Transformer and so on.
