• Model NO.：GDZRC-100U
• Size：440*245*395mm
• Weight：instrument: 19.5kg; accessory case: 7.5kg
• Transport Package：Plywood Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030849000
• Production Capacity：2000 Sets,Year

Output current

100A, 50A, 20A, 10A, 5A

Min. resolution

0.1μΩ

Measurement range

At 100A: 50μΩ~100mΩ;

at 50A: 100μΩ~200mΩ;

at 20A: 200μΩ~800mΩ;

at 10A: 500μΩ~2Ω;

at 5A: 1mΩ~4Ω

Accuracy

±(0.2%+2digits)

Working temperature

0ºC~40ºC

Relative humidity

<90%RH(no condensing)

Size

440*245*395mm

Weight

instrument: 19.5kg; accessory case: 7.5kg

Accessories

Tester

1 set

Power cord

1pc

Test line

1 set

Printing paper

1 roll

Fuse

2pcs

Ground cable

1pc

RS232 communication line

1pc

Test object

1pc

User's guide

1 copy

Warranty card

1 copy

Factory test report

1 copy
