GDUD-PTI Ultrasonic Flaw Detector Thickness Tester


DESCRIPTION

GDUD-PTI Uses some modern high and new technologies, such as ultrasonic flaw detection, thickness measurement, computer, electronic, die and process, and realized the perfect combination of these high and new technologies. For the industry to provide a superior performance, more powerful detection thickness measurement machine.



APPLICATIONS

Surface Breaking Cracks
Surface Crack Detection Using Sliding Probes

Tube Inspection
Thickness Measurements of Thin Material


FEATURES



• It's small and light in weight, the overall size of the whole machine is 180 * 130 * 40MM, including the weight of the battery is only 0.75kg, the operation and portability are very convenient, and the anti-interference ability is strong.
• 5.0 inch (800 × 480) widescreen color high resolution TFT LCD screen.
• The instrument comes with the thickness gauge calibration test block. With a separate thickness of the operating software interface, thickness measurement accuracy of 0.01mm.
• With wireless network function, to achieve the instrument and mobile Internet, remote access to remote storage through mobile phone files.
• With digital filtering function, precise selection of frequency bands, it can well filter out clutter when detecting the coarse material such as casting.
• The B scan showed that the defect display was more intuitive.
• With HDMI interface, can connect monitors and projectors.
• With TF card interface, scalable storage capacity, convenient data transfer.
• Instrument built-in 11 sets of national standards, compatible with European standard EN12668-1:2010, easy to set all kinds of DAC, AVG curve parameters.
• With dynamic waveform storage, dynamic waveform playback, screen copy function.
• Power saving design can work continuously for more than 10 hours.

SPECIFICATIONS



Transmit pulse	Square wave, transmit voltage 25~400V (step 25V), width 30~1000ns (step 0.1ns, 1.0ns, 10ns, 100ns)
Work mode	Single, double
Impedance matching	50Ω, 100Ω, 150Ω, 400Ω
Frequency band selection	0.5~4MHz, 2~8MHz, 0.5~20MHz
Gain range	0.0~110.0dB(step 0.1dB, 1.0dB, 2.0dB, 6.0dB)
Detection range	2.0~14000.0mm(steel longitudinal wave),Continuously adjustable
Detection mode	Positive half wave, negative half wave, full wave, radio frequency (RF)
Pulse translation	-45.0~10000.0mm
Probe bias	0.00~100.00μs(step 0.01μs, 0.1μs, 1.0μs, 10μs)
Pulse repetition frequency	15.0~1000.0Hz(step 0.1 Hz, 1.0 Hz, 10 Hz, 100 Hz)
Vertical linearity	≤3%
Horizontal linearity	≤0.3%
Sensitivity margin	>62dB(200Φ2 flat bottomed hole)
Resolution	>36dB
Dynamic Range	≥32dB
Inhibition	0~99%,  Does not affect the linearity and gain
RF output impedance	50Ω
Electric noise level	<10%
Interface	Q9 probe interface
Power supply	large capacity lithium battery, no memory effect, continuous work for more than 10 hours; 220V AC (with power adapter)
Ambient temperature	-10ºC~40ºC
Relative humidity	20%~95%RH
