• Model NO.：Voltage Distribution Tester
• Weight：1kg
• Power Source：AC220V
• Working voltage：35 - 1000kV
• Voltage measurement range：0 - 40kV
• Measurement error：≤±1%
• Resolution：0.01kV
• Sampling rate：10 times,second
• Working temperature：-35ºC---+60ºC
• Transport Package：Standard Export Wooden Box
• Specification：400*315*135mm
• Trademark：HV Hipot
• Origin：Wuhan, China
• HS Code：9030899090

Working voltage

35 - 1000kV (applicable for different voltage grades)

Voltage measurement range

0 - 40kV (can be customized)

Measurement error

≤±1%

Resolution

0.01kV

Sampling rate

10 times/second

Working current

≤ 120mA (for hand-held terminal), ≤ 40mA (for detector)

Power supply

2pcs 1.5V AA size dry battery (for hand-held terminal)

2pcs 1.5V AAA size dry battery (for detector)

Working time

More than 12 hours (continuously)

Detector and handheld terminal line-of-sight transmission distance

≤100m(full power)

Display

LCD display, legible in the sunlight.

Working temperature

-35ºC---+60ºC

Storage temperature

-40ºC---+65ºC

Relative humidity

≤ 90%RH (no condensing)
