• Model NO.：DH-MI-BP
• After-sale Customer Service：Yes
• Transport Package：Standard Exporting Wooden Package
• Trademark：DahoMeter
• Origin：Dongguan, China
• HS Code：9027809900
• Production Capacity：300 Sets,Month

Usage:

It is used to determine the melt mass rate flow rate MFR value or melt volume rate flow rate MVR value of various plastics and resin polymers in the viscous flow state. It is suitable for polycarbonate, polyarylsulfone,fluoroplastics and nylon which has higher melting temperature.It is also suitable for polyethylene (PE), polystyrene (PS), polypropylene (PP), ABS resin, polyoxymethylene (POM), and polycarbonate (PC) resins.which has lower melting temperatures

Remarks: Testing fluorine material is optional

Application industry:

Plastics industry; rubber industry; metrological quality inspection; colleges and universities; research institutes; commodity inspection and arbitration, technical supervision departments; petrochemicals; electrical appliances; composite materials;and other industries.

According to the standards:

The melt flow rate meter is suitable for the determination of the mass flow rate of thermoplastic melts specified in the national standard GB/T3682.1-2018 Determination of melt flow rate and melt volume flow rate of thermoplastics. It adopts the ISO 1133 regulations and meets the ASTM D1238 test standard. It complies with JB/T5456 "Melt Conditioner of Melt Flow Rate Meter" and JJG 878 - "Melt Flow Rate Meter" standard specification.

Main Features:

• DahoMeterModelDH-MI-BPDH-MI-VPDH-EI-BPDH-EI-VPDH-AI-VPWeight loading methodManualManualelectricElectricAutomaticTesting resultMassMass and volumeMassMass and volumeMass and volumeMFRMFR and MVRMFRMFR and MVRMFR and MVROutlet diameterΦ2.095±0.005mm,Outlet length:8.000±0.025mmLoading cylinder diameterΦ9.550±0.007mm,Loading cylinder length:152± 0.100mmPiston head diameterΦ9.475±0.007mm,Piston head length:6.350±0.100mmStandard test loadA total of 8 full set of weightsTemperature control rangeRoom temperature~400ºC(Optional~400ºC)Room temperature ~500ºCTemperature control resolution0.1ºC0.1ºC0.1ºCConstant temperature accuracy0.5ºC0.5ºC0.2ºCDisplacement resolutionNone0.001mm0.001mmTemperature control 4h driftNo less than ±0.5ºCCartridge temperature recovery time after feeding≤4minClock range0~6000sClock resolution0.1-1sCountdown time settingFreely setAutomatic cutting deviceSet the interval time (any adjustable from 2 to 2000s) ,automatically complete the cuttingJog cutting deviceManual button electric cuttingManual cutting deviceManually rotating the handle to cutWeight load accuracy≤±0.5%Weight load range325-21600g discontinuous, combined load can meet standard requirementsMeasuring range0.1~100g/10minPower supplyAC220V / 50HZ or AC110 /600HZ; Choose different power supply voltagesNet weight48KGGross weight63KG
  Packaging & Shipping:





  Company Information:

  We, Dongguan Hongtuo Instrument Co., Ltd, a China based company, are pleased to introduce ourselves as a notable testing equipments and machines manufacturer.Our company was established in the year 2000 with two primarily motto, which includes complete client satisfaction and to reach top-most position in the international market. The exceptional quality of our products like Gold Tester,Gold Testing Machine,Density Meter,Universal Tensile Testing Machine,Climatic Chamber,Melt Flow Index Tester,Charpy Impact Testing Machine,Tap Density Tester,Abrasion Tester,Ultrasonic Flaw Detector,Surface Roughness Tester and other Laboratory Testing Equipment, etc. is our company's USP.
