200A Micro Ohmmeter/Circuit Breaker Test Contact Resistance Tester

Sansion Power Electric Co., Ltd.

Display：LCD
Control：Computer Control
Weight：15kg
Power Source：AC220V
Current Range：200A
Duty：Continuous

Base Info

Model NO.：SXHL
Measuring Time Setting Range：15-60s
Input Voltage：220V AC 50Hz
Screen：LCD English Interface
Transport Package：Plywood Case
Specification：ISO9001 SGS
Trademark：Sansion
Origin：Wuhan, China
HS Code：9030339000
Production Capacity：1000 Units

Description

Measure range: 0-14999.9μΩResolution:0.01μΩTest current:50A-100A-150A-200A is convertible. (current is at your customized)Accuracy:0.5%±5digitScreen:LCD English interfaceMax. output voltage:DC 5V/10VStandard output current:DC 50A-100A-150A-200ADuty:ContinuousInput voltage:220V AC ±10% 50Hz±5HzMeasuring time setting range:15-60S
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!

200A Micro Ohmmeter/Circuit Breaker Test Contact Resistance Tester

200A Micro Ohmmeter/Circuit Breaker Test Contact Resistance Tester

200A Micro Ohmmeter/Circuit Breaker Test Contact Resistance Tester

200A Micro Ohmmeter/Circuit Breaker Test Contact Resistance Tester
