GDOT-80C Transformer Oil breakdown tester

HV Hipot Electric Co., Ltd.
  • After-sales Service：yes
  • Warranty：1 year
  • Mass Scope of Workpiece：<900kg
  • Type：Strength Testing Machine
  • Maxcapacity：80kV
  • Accuracy Grade：1

Base Info

  • Model NO.：GDOT-80C
  • Load Way：Electronic Load
  • Display：Digital
  • Control：Manual Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Output Voltage：0-80kv
  • Power Input：AC220V± 10%, 50Hz±1Hz
  • Capacity：1.5kVA;
  • Accuracy：±3%
  • Voltage Distortion Rate：≤3%
  • Voltage Increasing Speed：2.0-3.5kv,S, Adjusatble
  • Standing Time：15mins, Adjustable
  • Transport Package：Carton or Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030899090
  • Production Capacity：5000PCS,Year

Description

Operating environmentTemperature: 0ºC-45ºCHumidity: Max. relative humidity 75%Dimension465x385x425mm
GDOT-80C Transformer Oil breakdown tester
GDOT-80C Transformer Oil breakdown tester
