• Model NO.：GD-H1311
• Temperature Control Mode：Digital Display Pid Temperature Control
• Temperature Control Range：Normal Temperature ~ 250c
• Heating Method：Metal Bath Heating
• Pressure Regulation：High Precision Needle Valve
• Transport Package：Plywood
• Trademark：GOLD
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-H1311 Temperature Control Mode Digital Display Pid Temperature Control Temperature Control Range Normal Temperature ~ 250c Heating Method Metal Bath Heating Pressure Regulation High Precision Needle Valve Transport Package Plywood Trademark GOLD Origin Made in China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

ASTM D5800 Noack Volatility Tester for Evaporation Loss of Lubricating Oils by the Noack Method



Introduction:

The ASTM D5800 Noack Volatility Tester is used to determine the amount of evaporation loss of lubricating oil. The weighed sample was placed in a crucible for heating, and the mass of the evaporation loss of the test sample was measured by heating at a constant temperature and suction pressure by heating for 1 hour, expressed as a percentage loss.


Key Features:


1. The latest technology: replace the Noack A method, the test process does not require Wood Alloy to avoid environmental pollution and personal injury.

2. Control mode: embedded operating system, high-speed microprocessor control, stable and reliable work.

3. Printing method: USB printer interface, RS232 interface.

4. Touch screen: LCD display, convenient touch screen operation.

5. Security: Built-in diagnostic program and various alarm functions.

6. Precision control: built-in large-capacity EPROM, real-time recording of temperature and pressure values at each moment.


Parameters:

1. Applicable standards: ASTM D5800, DIN51581, NFT60616, CECC40A9S, SH/T0059.
2. Temperature control mode: digital display PID temperature control
3. Temperature control range: normal temperature ~ 250 ± 0.5ºC
4. Heating method: metal bath heating
5. Pressure regulation: high precision needle valve
6. Suction method: vacuum pump
7. Metal bath heating device, safe and environmentally friendly
8. Imported inclined tube differential pressure gauge to ensure accurate pressure
9. Equipped with a special vacuum pumping system
10. Digital timer to record the test time


Welcome to visit us!
