• Model NO.：YTST-216
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：Under
• Test Zone Size(W*H*D)：600*600*600mm
• Exterior Chamber Size(W*H*D)：1510*2050*2000mm
• Hot Zone Temp. Range：80c to 200c
• Cold Zone Humidity Range：-10c to -70c
• Temp.& Humidity Fluctuation：+,-0.2c
• Temp.&Humidity Uniformity：85c at Most
• Temp.& Humidity Resolation：0.01c,0.1%Rh
• Customization Service：Yes
• Controller：Temi 1500
• Power Supply：3 Phase 380V 50,60Hz
• Transport Package：Strong Wood Carton
• Specification：CE, SGS, TUV certified.
• Trademark：Yuanyao
• Origin：Dongguan, China(Mainland)
• HS Code：9031200000
• Production Capacity：20 Sets,Week

ModelYTST-056YTST-087YTST-126Internal Dim.W×H×D(mm)400×350×440500×350×500600×350×600External Dim.W×H×D(mm)1500×2050×21201600×2050×22201700×2050×2320Pre-heat Limit+200°CPre-cool Limit-60°C     -75°CTest Temp. Range+60°C ~+150°C;   -10°C~-50°C;   -10°C~-65°CPerformanceTemp. Constancy±2°CTemp. Recover TimeWithin 5 minsHeat-up Time°C150150150min303030Pull-down Time°C-50       -65-50       -65-50       -65min90       9090       9090       90MaterialExteriorStainless steel plate + Powder CoatedInteriorSUS # 304 stainless steel plate (Hairline Finish)InsulationPU & FiberglasswoolSystemsCirculationsiroco fanHeatingstripped wire heaterRefrigerationCompressor+Evaporator fins+water-cooling condenserController1POther ComponentsExper iment separation shelves(freely adjustable 2pcs)Safety DevicesNo fuse breaker,Motor overload protection High/low pressure shut off device,
Open door operation prevention switch, Flow switch protector cooling water.Power Source(K.W.)AC 1Ψ 220V;3Ψ 380V 60/50Hz90       9090       9090       90


Other styles / size with different configurations are available upon request.

Welcome to enquire and purchase !
