• Model NO.：GDYD-1010D
• Control：Manual Control
• Power Source：AC220V
• Power Supply：AC220V±10%, 50Hz
• Capacity：10kVA (based on selectable)
• HV Source：Epoxy resin cast HT transformer(Dry type testing t
• Output control：Manual control
• Metering：Digital display, kV meter: AC 0-100kV, mA meter: A
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030332000
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GDYD-1010D Control Manual Control Power Source AC220V Power Supply AC220V±10%, 50Hz Capacity 10kVA (based on selectable) HV Source Epoxy resin cast HT transformer(Dry type testing t Output control Manual control Metering Digital display, kV meter: AC 0-100kV, mA meter: A Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/Year

Product Description

I. General information

AC hi-pot testing is the effective and direct way to test insulation strength for electrical equipments, apparatus or machines. It checks dangerous flaws which assure electrical equipment continuous working.
Typical applications include testing of transformers, switchgear, cables, capacitors, aerial motors platforms, hot sticks bucket bricks, vacuum bottles and other related equipment like vacuum interrupters, blankets, ropes, gloves, hydraulics hose, instruments transformers generators.

II. Features

Digital display panel mounted controls & indicators with easy to read legend.
Monitoring high voltage side voltage,low voltage side current and indicator of zero, power, working start,timing.
Over-current protection, zero-starting protection, sound and light alarm.
Continuously variable output from zero to full voltage.
Adjustable over current protection,with trip levels variable from 10 to 110%.
With new type time relay, time range is more wider (1S ~ 99H).
Using the latest current relay, more accurate and reliable.
Light weight, small size, easy to move.


III. Specifications


Input	AC220V ± 10%
Frequency	50Hz ± 1
Output	0-100kV,  AC RMS
Rating	100%Rated-1minute, 50%-continuous
Capacity	10kVA (based on selectable)
HV Source	Epoxy resin cast HT transformer(Dry type testing transformer)
Output control	Manual control
Voltage accuracy	≤ 1.0% (F.S)
Current Accuracy	≤ 1.0% (F.S)
Timing range	0-99H
Metering	Digital display, kV meter: AC 0-100kV, mA meter: AC 0-100mA
Humidity	85% RH
Environmental temperature	-20ºC~50ºC
Weight	Control Unit:About 40kg Dry Type Testing transformer:About 75kg.
