3345-3 5A Lithium Polymer Battery Pouch Cell Test Clamp
XIAMEN TOB NEW ENERGY TECHNOLOGY CO., LTD.- After-sales Service：Life Time Support
- Warranty：1 Year
- Type：Battery Test Clamp
- Application：Lithium-ion Battery
- Transport Package：Standard Packing
- Trademark：TOB
Base Info
- Model NO.：TOB-3345-3
- Origin：China
Description
Basic Info.
Model NO. TOB-3345-3 Origin ChinaProduct Description
3345-3 5A Lithium Polymer Battery Pouch Cell Test Clamp
| Model | 3345-3 |
| Working temperature range | ≤125ºC |
| Current | 3~5A |
| Contact Resistance | ≤25mΩ |
| Insulation Resistance | 500VDC≥1×109 Ω |
| Flame retardant rating | UL94V0 |
| MOQ | 10 sets/bag |
| Remark | Based on the maximum current division of the customer test battery, so can be customized according to your needs. |
