Car Drive in Temperature Moisture Endurance Machine
Guangdong Yuanyao Test Equipment Co., Ltd.- Certification：CE
- Warranty：1 Year
- Inner Size：2*2*2m
- Temp. Range：0 Degrees~ +70degrees
- Humidity Range：30% Rh--90%Rh
- Temp. Fluctuation：+,-0.3 Degree
Base Info
- Model NO.：YWER-8000
- Humi. Fluctuation：+,-2.5%Rh
- Color：Ivory
- Interior Chamber Material：SUS#304 Stainless Steel Plate
- Exterior Chamber Material：Stainless Steel Plate + Powder Coated
- Insulation System：PU&Fiberglass Wool
- Wind Circulation System：Siroco Fan
- Transport Package：Strong Plywood Case
- Specification：CE, SGS, TUV certified.
- Trademark：Yuanyao
- Origin：China
- HS Code：8419899090
- Production Capacity：10 Sets,Month
Description
Non-standardExterior chamber sizeW×H×D(mm) Temperature range 0ºC;-20ºC;-40ºC;-60ºC,-70ºC~+70ºC(+80ºC) Humidity range 30% RH~95%RH Temp.Humi fluctuation ±0.3ºC;±0.5%RH Temp.Humi uniformity ±3ºC;±5%RH Indication Resolution Temperature:0.01 humidity:0.1%RH Heat-up and Cool-down time Heat-up:2ºC/min(Average),cool-down time 1ºC/min(Average) Air cirulation system Centrifugal fan air circulation system Heating system SUS#Stainless steel high-speed heater Humidification system Electrothermal steam humidification Refrigeration system Compressor + Finned evaporator + Air (Water) cooled condenser Dehumidifying system Dew point dehumification method Controlling system Touch screen controller+SSR+PID Exterior chamber material Cold rolled plate + Powder coating Interior chamber material SUS#304 Stainless steel Insulation material PU +fibergalss wool components Vacuum glass observation window
Test hole (50mm)
Control status indicator
Interior light Safety protection device Overheat protection circuit breaker
Humidification system overheat protection
Compressor overload protection
Control system overload protection
Overload indicator
Phase sequence protection
Water shortage protection
High voltage and low voltage protection
Over temperature protection
Water supply delay protection
Fan overcurrent protection Power supply AC 3Ψ380V 60/50Hz (Power supply can be customized) Customization service Non-standard or special requirements are all welcome
Except Car drive in temperature moisture endurance machine, Guangdong Yuanyao Test Equipment Co., Ltd also can supply:
Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Automatic dispenser robot, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.
More details about the specification, please contact us, thanks for your attention.
