Htt-01 Hot Tack Tester Hot Tack Machine Heat Seal Tester Heat Seal Strength Tester
Pubtester Instruments Co., Ltd.- Warranty：12 Months
- Display：Digital
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Sealing Temperature：Room Temperature ~ 300 °c
Base Info
- Model NO.：HTT-01
- Dwell Time (Heat Seal Test)：0.1~ 999.9s
- Dwell Time (Hot Tack Test)：0.1~ 999.9s
- Sealing Pressure：0.05 MPa ~ 0.7 MPa
- Sealing Area：100 mm X 5mm
- Load Cell Capacity：0~200 N ( 30n, 50n, 100n, 500n Optional )
- Trademark：Pubtester
- Origin：China
Description
Extended ApplicationMedical Adhesives Peeling test and tensile strength test of medical adhesives e.g. adhesive bandages Adhesive Tapes Low speed unwrapping test Textiles, Nonwovens and Woven Bags Peeling test and tensile strength test Protection Films Peeling test and tensile strength test Magnetic Cards Peeling test of the films and magnetic cards Bottle Caps Opening force test of the aluminum plastic combination bottle caps
Standards
ASTM F1921, ASTM F2029, QB/T 2358, YBB 00122003
Configuration
Standard configuration: Instrument, 7-inch touch screen, Pedal Switch, Hot tack Clamp, Calibration bracket
Optional configuration: Professional software, communication cable, non-standard sealing jaw, testing board, welding cloth, non-standard fixture, sampler, non-standard sample positioning board.
Note: 1. Φ4 mm PU port for gas supply port;
2.Customer need to prepare gas.
About Us
Established in Jinan, China, Pubtester Instruments Co., Ltd has developed into a major manufacturer and supplier of flexible packaging testing instruments in China. In the year of 2020, Pubtester launched a series of testing instruments specilized in medical device (medical dressings, syringes, catheters, gloves and aseptic packaging, etc), which meet the increasing testing demand for medical industry since 2019. Pubtester has its own packaging testing center, equipped with more than 80 sets of testing instruments, which can perform barrier, force and strength, heat sealing, hot tack, coefficient of friction, thickness, tearing, impact, heat resistance, leakage, flex durability , adhesion, color, fastness and other testing items, and provide testing services to customers. By 2021, Pubtester instruments have been exported to more than 40 countries and areas including UK, Germany, Portugal, Spain, Turkey, Greece, Ukraine, UAE, Saudi Arabia, Tunisia, Nigeria, Morocco, Kenya, Thailand, Malaysia, India, Indonesia, Vietnam, Columibia, Mexico, etc. Pubtester has a great technical team of professionals, all of whom have more than 10 years experience in packaging testing industry, which provide our customers with comprehensive technical services and solutions all the time.
| Specifications | HTT-01 |
| Sealing Temperature | Room temperature ~ 300 °C |
| Temperature Accuracy | ±0.2 °C |
| Dwell Time (Heat Seal Test) | 0.1~ 999.9s |
| Temperature Uniformity | ± 1 °C |
| Dwell Time (Hot Tack Test) | 0.1~ 999.9s |
| Sealing Pressure | 0.05 MPa ~ 0.7 MPa |
| Sealing Area | 100 mm ×5mm |
| Heating Mode | Single or Double Heating Surfaces (Customization) |
| Gas Supply Pressure | 0.5MPa~0.7MPa (Not in Supply Scope) |
| Port Size | Φ4mm PU Tubing |
| Load Cell Capacity | 0~200 N ( 30N, 50N, 100N, 500N optional ) |
| Force Accuracy | 0.5% FS |
| Force Resolution | 0.001N |
| Test Speed | 0.05 ~ 3000 mm/min |
| Specimen Width | 15 mm, 25 mm or 25.4 mm (Customization) |
| Stroke | 500 mm |
| Instrument Dimension | 1170mm (L) × 360 mm (W) × 460 mm (H) |
| Power Supply | AC 220V 50Hz / AC 120V 60HZ |
| Net weight | 45 kg |
ASTM F1921, ASTM F2029, QB/T 2358, YBB 00122003
Configuration
Standard configuration: Instrument, 7-inch touch screen, Pedal Switch, Hot tack Clamp, Calibration bracket
Optional configuration: Professional software, communication cable, non-standard sealing jaw, testing board, welding cloth, non-standard fixture, sampler, non-standard sample positioning board.
Note: 1. Φ4 mm PU port for gas supply port;
2.Customer need to prepare gas.
