20A Three Phase Transformer DC Winding Resistance Test Instruments
Sansion Power Electric Co., Ltd.- Display：LCD
- Current Range：Customized
- Test Current：Automatic, <20mA, 40mA, 200mA, 1A, 5A, 10A
- Minimum Resolution：0.1μΩ
- Data Storage：1000 Groups
- Maximum Power Consumption：200W
Base Info
- Model NO.：SXZR
- Transport Package：Plywood Case
- Specification：ISO9001 SGS
- Trademark：Sansion
- Origin：Wuhan, China
- HS Code：9030332000
- Production Capacity：100 Units
Description
Test Current
2.5A 5A 10A 20A (Current range is at your customized)
Measuring range
2.5A:
5A:
10A:
20A:
2mΩ~16Ω
800μΩ~8Ω
400μΩ~4Ω
200μΩ~2Ω
Measuring precision
±0.2%(full scale)
Max. resolution
0.1μΩ
Power source
AC 220V±10%,50Hz±1 Hz
Working condition
Temperature:0°~40°RH:≤90% no condensation
Oversize
425500180(mm)
Please kindly contact with us for further information.
