• Model NO.：GW-049B
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：100-500Kg
• Power Source：AC220V
• Oil Cylinder Position：Electric Control
• Packaging：Wooden Case
• Export Markets：Global
• Model No：Gw-049b
• Test Speed：5,10,15,20,25,45 mm,Min Can Be Changed
• Maximum Load：2t
• Unit：Kg, N, Lb Can Be Arbitrary Switch
• Power：AC 220V 50Hz
• Volume：71*30*76 Cm
• Transport Package：Wooden Case
• Specification：71*30*76cm
• Trademark：Great Win
• Origin：China
• HS Code：9024800000
• Production Capacity：500 Pieces,Year

Basic Info.

Model NO. GW-049B Loading Method Static Load Display Digital Control Manual Control Weight 100-500Kg Power Source AC220V Oil Cylinder Position Electric Control Packaging Wooden Case Export Markets Global Model No Gw-049b Test Speed 5/10/15/20/25/45 mm/Min Can Be Changed Maximum Load 2t Unit Kg, N, Lb Can Be Arbitrary Switch Power AC 220V 50Hz Volume 71*30*76 Cm Transport Package Wooden Case Specification 71*30*76cm Trademark Great Win Origin China HS Code 9024800000 Production Capacity 500 Pieces/Year

Product Description

GW-049B Safety shoes compression & puncture testing machine


Brief introduction:
This Machine is used to test the compression of safety footwear and puncture resistance of shoe sole, the instrument will automatically retain test values.
Technicla Specifications:

Model	GW-049B Safety shoes compression & puncture testing machine
Test speed:	5/10/25/45 mm/min can be changed, also can be infinitely adjustable-speed
The maximum load:	2000 kg
Unit:	kg, N, Ib can be arbitrary switching
Display:	LED display
Voltage:	AC220V
Volume:	71*30*76cm
Weight:	108kg



Standard for:
GB/T20991-2007 5.5,ISO EN 20344:2004.


Attached accessories:
The compression strength grips and punctured resistance grips
3pcs standard modeling clay moulds
2pcs hexagon wrench
5pcs steel puncture needles
5pcs modeling clay
What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.

What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.

What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.

What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
