Ndw Series Computer Software Control Metal Material Torsion Testing Machine
Jinan Kason Testing Equipment Co., Ltd.- After-sales Service：Online Technical Support
- Warranty：1 Year
- Max Diameter of Workpiece：500mm
- Mass Scope of Workpiece：5000kg
- Type：Torsion Testing Machine
- Maxcapacity：100n,M
Base Info
- Model NO.：NDW
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Computer Control Display
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC380V
- Oil Cylinder Position：Under
- Transport Package：Plywood Exporting Package
- Specification：350kg, 1.35CBM, color can customize
- Trademark：HST
- Origin：Jinan, Shandong, China
- HS Code：9024109000
- Production Capacity：1000 Sets,Month
Description
NDW-200NDW-500 NDW-1000 NDW-2000 NDW-3000 NDW-5000 Maximum Torque(N/m) 100 200 500 1000 2000 3000 5000 Control Method Constant torque and constant speed rotation, constant speed twist angle , close loop control mode Machine level 1 Class Torque Test Range(F·S) 2%~100%F·S Torque value relative error(%) ≤±1 Torque display resolution 1/20000 Torsional Angle Test Range(F·S) 2%~100% Torsional Angle value relative error (%) Better than ±0.5 Torsional Angle display resolution 1/20000 intersection angle value relative error (%) ≤±1 intersection angle display resolution(°) 0.01 Max. torsion Angle 99999° Torsional angular rate control range (°/min) 0.05-800 Chuck spacing effectively (mm) 600 Power Supply 220V±10%,50Hz
