ASTM D 1894 Cof-01 Plastic Film Coefficient of Friction (COF) Tester
Pubtester Instruments Co., Ltd.- Warranty：12 Months
- Display：Digital
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Capacity Range：5n (Standard) 10n, 30n, 50n, 100n (Optional)
Base Info
- Model NO.：COF-01
- Test Accuracy：0.1%Fs
- Stroke：300 mm
- Sled Mass：200g (Standard), 500g (Optional)
- Test Speed：100mm,Min, 150mm,Min 0.05 ~500mm,Min
- Trademark：Pubtester
- Origin：China
Description
Extended ApplicationEye Drops Medical Tubes
Technical Specifications
Standards
ASTM D 1894, ISO 8295, TAPPI T816, GB 10006
Configuration
Standard Configuration: Instrument, Micro-printer, 200g Sled
Optional Parts: 500g Sled, Non-standard Sled
About Us
Established in Jinan, China, Pubtester Instruments Co., Ltd has developed into a major manufacturer and supplier of flexible packaging testing instruments in China. In the year of 2020, Pubtester launched a series of testing instruments specilized in medical device (medical dressings, syringes, catheters, gloves and aseptic packaging, etc), which meet the increasing testing demand for medical industry since 2019. Pubtester has its own packaging testing center, equipped with more than 80 sets of testing instruments, which can perform barrier, force and strength, heat sealing, hot tack, coefficient of friction, thickness, tearing, impact, heat resistance, leakage, flex durability , adhesion, color, fastness and other testing items, and provide testing services to customers. Pubtester has a great technical team of professionals, all of whom have more than 10 years experience in packaging testing industry, which provide our customers with comprehensive technical services and solutions all the time. Pubtester, is always dedicated to be the packaging testing expert by your side.
Technical Specifications
| Specifications | COF-01 |
| Capacity Range | 5N (Standard) 10N, 30N, 50N, 100N (Optional) |
| Test Accuracy | 0.1%FS |
| Test Platform Temperature | Room temperature |
| Stroke | 300 mm |
| Sled Mass | 200g (standard), 500g (optional) Customization is available for other masses |
| Test Speed | 100mm/min, 150mm/min 0.05 ~500mm/min (stepless speed regulation) |
| Specimen Height | 0 ~ 30mm |
| Power Supply | AC 220V 50Hz/120V 60Hz |
| Instrument Dimension | 600mm (L)×330 mm (W)×230 mm (H) |
| Net Weight | 35.2 kg |
Standards
ASTM D 1894, ISO 8295, TAPPI T816, GB 10006
Configuration
Standard Configuration: Instrument, Micro-printer, 200g Sled
Optional Parts: 500g Sled, Non-standard Sled
