Battery Internal Resistance Analyzer

Sansion Power Electric Co., Ltd.
  • Type：Storage Battery Tester
  • Test Region：Internal Resistance
  • Internal Resistance：0.00m Ohm-100.00m Ohm
  • Voltage：0-16V
  • Screen：Touch
  • Storage：1500 Batteries′ Parameters

Base Info

  • Model NO.：SXDC-II
  • Transport Package：Carton or Plywood Case
  • Specification：SGS
  • Trademark：Sansion Power
  • Origin：Wuhan, China
  • HS Code：9030899090
  • Production Capacity：100 Set,Per

Description

Measuring Range:Internal resistance:0.00mΩ-100.00mΩ
Voltage:0.00V-16V
Withstand voltage: 0.00v-220VMin. Measuring Resolution:Internal resistance:0.01mΩ
Voltage:1mVMeasuring Precision:Internal resistance:±1.0%rdg ±6dgt
Voltage:±0.2%rdg ±6dgtPower Source:High performance rechargeable lithium batteryPower Consumption:Continuous working 8 hours.Storage:1500 batteries' parametersDisplay:192*64 dot-matrix LCD screenSize:230×158×60MMWeight:0.6 KgCommunication:USB port
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
