Test Instrument

GDZRC -40A DC winding resistance tester

HV Hipot Electric Co., Ltd.
  • After-sales Service:yes
  • Function:Cleared
  • Display:Digital
  • Usage:Electric Component Tester
  • Type:Resistance Tester
  • Environment:Room Temperature

Base Info

  • Model NO.:GDZRC -40A
  • Warranty:With Warranty
  • Power Source:AC 85V-265V
  • Customized:Non-Customized
  • Model number:GDZRC-40A
  • Power supply:AC 220V±22V,50Hz±2 Hz
  • Test current:2.5A, 5A, 10A, 20A, 40A
  • Data storage capacity:±0.2% (full scale)±2digit
  • Mini. resolution:255PCS
  • Working environment:0-40°C, RH humidity≤80%
  • Delivery time:10 days
  • Transport Package:Wooden Case
  • Specification:ISO, SGS
  • Trademark:HV Hipot
  • Origin:Wuhan China
  • HS Code:9030332000
  • Production Capacity:3000PCS,Year


Basic Info.

Model NO. GDZRC -40A Warranty With Warranty Power Source AC 85V-265V Customized Non-Customized Model number GDZRC-40A Power supply AC 220V±22V,50Hz±2 Hz Test current 2.5A, 5A, 10A, 20A, 40A Data storage capacity ±0.2% (full scale)±2digit Mini. resolution 255PCS Working environment 0-40°C, RH humidity≤80% Delivery time 10 days Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 3000PCS/Year

Product Description


GDZRC series DC winding resistance tester is designed to measure DC resistance ofinductive devices, such as transformers and power inductors. It has features of fastmeasurement, small size and high accuracy, which make it an ideal equipment for measuring DC resistance of transformer winding and high inductive equipment.


1. Four leads measurement to ensure measuring accuracy.
2. Program-controlled current source to increase measuring speed.
3. Auto discharge and discharge indication function, to ensure safety and availability.
4. LCD screen and Built-in Printer.


Test current2.5A, 5A, 10A, 20A, 40A
Measurement range2.5A: 10m-8Ω
5A: 1mΩ-4Ω
10A: 1mΩ-2Ω
20A: 1mΩ-1Ω
40A: 1mΩ-500mΩ
Measurement accuracy±0.2% (full scale)±2digit
Mini. resolution0.1μΩ
Data storage capacity255pcs
Power supplyAC 220V±22V, 50Hz±2Hz
Environmental temperature0°C~40° C
RH humidity≤80%
