Test Instrument

Aging Performance Tester for PVC Sheet Under High Temperature Environment

Harbin Hapro Electric Technology Co., Ltd.
  • After-sales Service:a Lifetime
  • Warranty:1 Year
  • Max Diameter of Workpiece:>3200mm
  • Mass Scope of Workpiece:<900kg
  • Type:Universal Testing Machine
  • Maxcapacity:<1000KN

Base Info

  • Accuracy Grade:1
  • Load Way:Electronic Load
  • Loading Method:Dynamic Load
  • Display:Digital
  • Control:Touch Screen
  • Weight:100-500Kg
  • Power Source:AC380V
  • Oil Cylinder Position:No
  • Max.Temperature:350;
  • Power of Motor:400 W
  • Motor:Schneider Servo
  • Aging Time:1min~ Two Months
  • HMI:Delta Touch Screen
  • Heating:Electrical Heating
  • Transport Package:Plywood
  • Trademark:Hapro
  • Origin:China
  • HS Code:9024800000
  • Production Capacity:100,Year

Description












 MotorSchneider servoPower of Motor400 WMotor Speed8000r/minTray, L×H×WA 6 lines:291×6×24 mm
B 7 lines:291×7×16 mmPreheating timeSetableSampling time1minAging time1min~ two monthsHMIDelta touch screenDynamic speed ratio1:200000Aging temperatureRT ~350ºCTemp control systemRKC systemHeatingElectrical heatingHeating power200W×20Temperature sensorJ type thermocouple ×4Power supply voltage3-phase 380VWeight350 kgDimension (L×W×H)   841×540×1200mm
