AC Dielectric Test System (Manually Control Table+Gas Type Testing Transformer)

HV Hipot Electric Co., Ltd.
  • Type：Withstand Voltage Test Set
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Manual Control
  • Power Source：AC220V

Base Info

  • Model NO.：GDYD-1010D
  • Input：AC220V ± 10%
  • Frequency：50Hz ± 1
  • Output：0-100kV, AC RMS
  • Rating：100%Rated-1minute, 50%-continuous
  • Capacity：10kVA (based on selectable)
  • HV Source：SF6 gas(Gas Type Testing Transformer)
  • Output control：Manual control
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030332000
  • Production Capacity：2000PCS,Year

Description

Basic Info.

Model NO. GDYD-1010D Input AC220V ± 10% Frequency 50Hz ± 1 Output 0-100kV, AC RMS Rating 100%Rated-1minute, 50%-continuous Capacity 10kVA (based on selectable) HV Source SF6 gas(Gas Type Testing Transformer) Output control Manual control Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/Year

Product Description

AC Dielectric Test System (Manually Control Table+Gas Type Testing Transformer)

Technical Specifications

InputAC220V ± 10%
Frequency50Hz ± 1
Output0-100kV,  AC RMS
Rating100%Rated-1minute, 50%-continuous
Capacity10kVA (based on selectable)
HV SourceSF6 gas(Gas Type Testing Transformer)
Output controlManual control
Voltage accuracy≤ 1.5% (F.S)
Current Accuracy≤ 1.5% (F.S)
Timing range 0-99H
MeteringDigital display, kV meter: AC 0-100kV, mA meter: AC 0-100mA
Humidity85% RH
Environmental temperature-20ºC~50ºC
WeightControl Unit:About 40kg
Gas Type Testing transformer:About 68kg.
AC Dielectric Test System (Manually Control Table+Gas Type Testing Transformer)
