50 Kg Belt Drive Balancing Machine for Rotors
Shanghai Jianping Dynamic Balancing Machine Manufacturing Co., Ltd.- Mass Scope of Workpiece：<900kg
- Type：Balancing Machine
Base Info
- Model NO.：PHQ-50
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC380V
- Place of Origin：Shanghai, China
- Brand Name：Jp
- Model Number：Phq-50
- Length：1100mm
- Width：900mm
- Height：1300mm
- Gross Weight：500kg
- Nunumber of Packing：2 PCS
- Output Power：0.75kw Frequency Conversion
- Power Supply：380V or Custom
- Transport Package：Packed in Fumigated Wood Box
- Specification：ISO9001: 2008, CE, SGS
- Trademark：JP
- Origin：Shanghai China
- HS Code：90311000
- Production Capacity：5000 Sets,Month
Description
Technical data at a glance
PHQ-50
Max Mass of Workpiece (kg)
50
Max Diameter of Workpiece (mm)
700
Distance between Two Support Bearings (mm)
80--700
Journal Diameter Scope of Workpiece (mm)
8~80
Diameter Scope of Driving Belt (mm)
18~200
Rotation Speed when the Diameter of Driving Belt is 100mm (r/min)
700/1050 Stepless speed regulation
Motor Power (kw)
0.75 Frequency conversion
Min Achievable Residual Unbalance Amount (emar)
0.5g· mm/kg
