Fra Frequency Response Analyser Measurement Transformer Maintenance Winding Deformation Test Equipment

Sansion Power Electric Co., Ltd.
  • Max Diameter of Workpiece：900mm
  • Mass Scope of Workpiece：<900kg
  • Type：Strength Testing Machine
  • Maxcapacity：>1000KN
  • Accuracy Grade：0.5
  • Load Way：Electronic Load

Base Info

  • Model NO.：SXBR-Z
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control
  • Weight：About 5kg
  • Signal Input Impedance：1mΩ
  • Oversize：35cm *21cm*21cm
  • Transport Package：Plywood Case
  • Specification：ISO9001 SGS
  • Trademark：Sansion
  • Origin：Wuhan, China
  • HS Code：9030891000
  • Production Capacity：100 Units

Description

6 modes scan method:Linear source:1K-1000KHZ_1.0  source point  1KHZ       10001K-1000KHZ_0.5  source point  0.5KHZ       20001K-2000KHZ_1.0  source point  1KHZ       20001K-2000KHZ_0.5  source point  0.5KHZ       4000Segmentation source:100HZ - 1000KHZ  source point  1440100HZ - 2000KHZ  source point  2440Measurement range:(-100dB)-(+20dB) Measurement precision:0.1dB Frequency sweeping precision:less than 0.01% Signal input impedance:1MΩ Signal output impedance:50Ω Same test repetition:99.5%
Pictures for reference using only. All our products exported out of China is in English interface.
More information please contact us Sansion Power Electric. Thank you!
