• Model NO.：SXFA-III
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Top
• Current Output：0~600A
• Output：0~1000V
• Transport Package：Plywood Case
• Specification：ISO9001 SGS GB DL
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030820000
• Production Capacity：100 Units

CT(Protection/measurement type)PTVolt-ampere characteristic(excitation) curveVolt-ampere characteristic(excitation) curveAuto calculates knee point valueAuto calculates knee point value5%and 10% error curveTurns ratioTurns ratioPolarityPolarityRatio errorPrimary Flow InjectionAngular errorRatio errorAC withstand testAngular errorDemagnetizationAC withstand test Demagnetization
 Working supplyAC220V±10% , 50HzOutput0~1000V(20A peak value)Current Output0~600AExcitation Measuring Precision≤0.5%(0.2%*read+0.3%*range)Phase measurement    (Angular Error)Precision±4minResolution0.1minRatio ErrorPrecision≤0.05%CT
Turns RatioRange5000A/1A(25000A/5A)Precision≤0.5%PT
Turns RatioRange1KV~500KVPrecision≤0.5%Working EnvironmentTemperature: -10ºC ~ 40ºC,Humidity: ≤90%,Altitude: ≤1000mSize and Weight400mm × 250mm × 250mm,  Weight≤22Kg More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
