• Model NO.：DH-VT-A1
• Trademark：DahoMeter
• Origin：Dongguan, China
• HS Code：9027809900
• Production Capacity：300 Sets,Month

Basic Info.

Model NO. DH-VT-A1 Trademark DahoMeter Origin Dongguan, China HS Code 9027809900 Production Capacity 300 Sets/Month

Product Description

DH-VT-A1 Vertical Electromagnetic Sweeping Vibration Table, Frequency-sweep Shaker Table 50Hz

Application

Electromagnetic vibration table is widely used in defense, aviation, communications, electronics, automobiles, home appliances, and other industries. This type of equipment is used to detect early failures, simulate actual working conditions, and structural strength tests. The product has a wide range of applications, wide application areas, and significant and reliable test results. Sine wave, frequency modulation, time control.


Features

1. Using the most advanced and simple operation technology, fixed frequency work mode.

2. With time timing, countdown display function

3. The control parameters are displayed synchronously in real time, without manual intervention.

4. The base of the machine adopts anti-vibration device, which is easy to install and runs smoothly, without installing anchor screws

5. Embedded amplitude prediction program and easy amplitude modulation

7. Four-point synchronous excitation, uniform table vibration

8. Stepless adjustment of amplitude, fixed frequency and sweep frequency operation functions to adapt to various test requirements of different industries

9. Increase the anti-interference circuit to solve the interference of the control circuit due to strong electromagnetic field



Specification


Test load:	30KG
Vibration direction:	Vertical
Table size (mm):	400mm*350mm*20mm
Amplitude (P-P):	0-5mm (random, change with frequency, adjustable)
Frequency sweep:	50HZ
Indicator function:	Time can be setup
Vibration waveform:	Sine wave
Time control:	Time can be set
Power:	0.5KW
