IEC62271 High Quality Dynamic Resistance Measuring Instruments High-Voltage Switch Mechanical Characteristics Tester

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Coil Current Measurement：Range: 0~20A; Resolution: 0.001A; Error:<0.01A
  • Vibration Measurement：Range: 0~5000g; Error:<3%
  • Internal DC Power Source：Voltage: 12~265V; Current:0~20A
  • Data Save：Built-in 8g Storage Memory and 2 USB Interface
  • Power Supply：AC220V±10%; 50Hz±10%
  • Working Environment：Temperature: -10~50°c; Humidity:<80%

Base Info

  • Model NO.：GDGK-307
  • Pre-Insertion Resistance Measurement：Range: 50~5000ohm; Error :<1%Rdg+2D
  • Time Measurement：Range: 4000ms Error :< 0.1ms Resolution: 0.01ms
  • Dynamic Resistance Measurement：Test Current: 25~100A Measurement Error :< 1%Rdg+2
  • MOQ：1 Set
  • Delivery Time：7 Days
  • Transport Package：Standard Wooden Case
  • Trademark：GOLD
  • Origin：China
  • Production Capacity：500 Sets,Month

Description

Speed measurement250mm linear resistance scale: 0~20m/s; error:<0.5%RDG+2D25mm linear resistance scale: 0~20m/s; error:<0.5%RDG+2DAngle sensor: 0~20m/s; error:<0.5%RDG+2DAcceleration sensor: 0~20m/s; error:<5%RDG+2DCoil current measurementRange: 0~20A; resolution: 0.001A; error:<0.01AVibration measurementRange: 0~5000G; error:<3%Internal DC power sourceVoltage: 12~265V; current:0~20AData SaveBuilt-in 8G storage memory and 2 USB interface for data export and external keyboard or mouse connectionPower supplyAC220V±10%; 50Hz±10%Working environmentTemperature: -10~50°C; Humidity:<80%
PRODUCT SHOW:
IEC62271 High Quality Dynamic Resistance Measuring Instruments High-Voltage Switch Mechanical Characteristics Tester
