Ultra High Performance Piezo Fast Steering Mirrors and Piezo Tilt Platform with 4.9 Degrees Tilt Angle for Laser Beam Steering Piezo Stage
Harbin Core Tomorrow Science and Technology Co., Ltd.- After-sales Service：Online
- Warranty：1 Year
- Active Axes：Tilt Along X Y Axes
- Transport Package：Carton
- Specification：Internal
- Trademark：CoreMorrow
Base Info
- Model NO.：P35
- Origin：China
- HS Code：8541600000
- Production Capacity：5000,Year
Description
Overview
Product Description
Characteristics
- θx, θy tilt
- Tilt angle to 43mrad/axis
- Resolution to 1μrad
- Unloaded resonant frequency to 1.75kHz
Product Parameters
P35 Technical data:Mass260 335 g±5% Note: Above parameters are measured with the E00/E01 piezo controller. The maximum driving voltage can be -20V~150V; For high-reliability and long-term operation, the recommended driving voltage is 0~120V.
www.made-in-china.com/showroom/xmtkj2012
Designed for high large-angle deflection applications, P35 Piezo Tip/Tilt Platforms provide beam deflections up to 86mrad (approximately 4.9 degrees, 17700"), making them ideal for fast deflection applications with high precision and large angle.
Characteristics
- θx, θy tilt
- Tilt angle to 43mrad/axis
- Resolution to 1μrad
- Unloaded resonant frequency to 1.75kHz
Product Parameters
P35 Technical data:Mass
