• Model NO.：HJ-66
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Touch Screen Controller
• Weight：40kg
• Power Source：AC220V
• Oil Cylinder Position：No
• Machine Size：About 450*330*500mm
• Indenter Requirements：Choose Round Bar Aluminum
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-66 Load Way Electronic Load Loading Method Static Load Display Digital Control Touch Screen Controller Weight 40kg Power Source AC220V Oil Cylinder Position No Machine Size About 450*330*500mm Indenter Requirements Choose Round Bar Aluminum Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Basic introduction
This instrument can simulate mobile phones and other products, imitate people's repeated seat pressure life test, use a round bar of aluminum with a certain hardness as the indenter, drive it with a cylinder, adjust a certain pressure of 17kg, and check the damage degree after measuring the number of arrivals.

Detailed introduction of mobile phone hard pressure testing machine
This instrument can simulate mobile phones and other products, and simulate the repeated seat pressure life test of people. A round bar of aluminum with a certain hardness is used as the indenter, driven by a cylinder, and a certain pressure is adjusted to 17kg. Meet the YD/T 1539-2006 standard. Unpack the mobile communication handset, install the matching battery, turn it on, lock the keyboard, face up, and place the body and the axis of the fixed bracket vertically on a round bar aluminum extrusion head with a length of 12cm (250±10 ) N, squeeze the sample 1000 times at a frequency of 15-30 times per minute, and then the function, appearance and assembly should meet the requirements of relevant standards. Handsets with foldable, sliding and rotating structures should be tested with their lids closed.


Test the largest sample	200cm*10cm, height adjustable within 4cm
control	touch screen control
working frequency	10~60 times/min
A set of calibration device	Pressure sensor 100kg
Alarm time	5-10 seconds (fixed)
Indenter requirements	Choose round bar aluminum
Machine size	About 450*330*500mm
weight	40kg
power supply	AC220/50HZ


      FAQ

1. Do you offer after-sales service? How can I ask for that? And how about the warranty?
   Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

   2.. What's the delivery term?
   At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
