• Model NO.：SXWH Series
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Testable Voltage：0.22kv-500kv
• Auto Power off：15 Minutes Standby Then Auto Power off
• Transport Package：Carton or Plywood
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9031809090
• Production Capacity：100 Units

Auto power off:15 minutes standby then auto power off.Sample rate:3 times/second.Build-in power supply:the control unit battery model is NEDA/604/6F22,9V or same style battery. X and Y collectors batteries are AG13,1.5V.Working conditions:-35ºC- +50ºC, humidity: ≤90%RH.Storage conditions:-40ºC- +55ºC, humidity: ≤95%RH.Accuracy:self calibrating error ≤2°. On-site testing: same phase error≤10°,out of phase≤15°.Power supply:9V±2VCollectors X and Y supply:7.5V±1.5V.Control unit working current:≤ 7mA.Collectors X and Y working current:≤ 4mA.Line-of-sight transmission distance between collector X, Y and control unit ≤ 70m.Testable voltage degree:0.22KV-500KV.Extensible insulating rod:min. length is 600mm, max. length is 3000mm.Carry case oversize:(L×W×H) 650mm×250mm×100mm.Weight:Control unit about 0.3Kg, total about 5Kg.Accessories:1 piece Aluminum alloy carrying case
1 piece test lead with AC 220V plug and clip
1 piece User's Guide
1 piece Test Report

Warranty: One year quality guarantee after shipment.
