• Model NO.：YG(B)086A
• Accuracy Grade：0.5
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Computer Control
• Weight：55kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Yarn Spindles：6
• Yarn Spacing：60mm
• Yarn Frame Circumference：1000mm
• Yarn Frame Speed：(20 ~ 220)R,Min
• Wisp Yarn Number：1 ~ 9999
• Horizontal Reciprocating：35mm
• Single Yarn Tension Range：(0 ~ 100)Cn
• Transport Package：Carton
• Trademark：Darong
• Origin：China
• HS Code：9024800000
• Production Capacity：2000PCS

Basic Info.

Model NO. YG(B)086A Accuracy Grade 0.5 Load Way Electronic Load Loading Method Static Load Display Digital Control Computer Control Weight 55kg Power Source AC220V Oil Cylinder Position Under Yarn Spindles 6 Yarn Spacing 60mm Yarn Frame Circumference 1000mm Yarn Frame Speed (20 ~ 220)R/Min Wisp Yarn Number 1 ~ 9999 Horizontal Reciprocating 35mm Single Yarn Tension Range (0 ~ 100)Cn Transport Package Carton Trademark Darong Origin China HS Code 9024800000 Production Capacity 2000PCS

Product Description

YG(B)086A thread length measuring machine (Warp Reel)






[Scope of application]
Used for accurately measuring yarn length, linear density or number of textile yarn and yarn strength test.
[Related standards]
GB/T4743 GB/T14343 GB/T6838 ISO2060 ASTM D1907, etc
Instrument characteristics
1, synchronous gear belt direct transmission, no impact ring slip.
2, photoelectric coupling tube counting.
3, imported electronic tension sensor, dynamic display of winding tension, no additional tension impact [YG (B) 086A]
Technical parameters
1. Yarn bursts can be tested at the same time
2. Yarn spacing: 60mm
3, yarn frame circumference :(1000±1)mm
4, yarn frame speed :(20 ~ 220)r/min (stepless speed regulation)
5, wisp yarn number: 1 ~ 9999
6. Horizontal reciprocating width of yarn shaking :(35±0.5)mm
7, single yarn tension range :(0 ~ 100)cN±1cN
8, power supply: AC220V±10% 50Hz 100W
9. Overall size :(780×660×480)mm
10, weight: 55kg
