ISO 8295 CE Floor Film Sheet Paper Coefficient of Friction Tester for Cof Testing
Pubtester Instruments Co., Ltd.- Capacity Range：5n (Standard)
- Test Accuracy：0.1%Fs
- Stroke：300 mm
- Sled Mass：200g (Standard), 500g (Optional)
- Test Speed：0.05 ~500mm,Min
- Specimen Height：0~30mm
Base Info
- Model NO.：COF-01
- Transport Package：Veneer Case
- Trademark：Pubtester
- Origin：Jinan, Shandong
- Production Capacity：10 Sets,Quarter
Description
Extended ApplicationEye Drops Medical Tubes
Technical Specifications
Standards
ASTM D 1894, ISO 8295, TAPPI T816, GB 10006
Configuration
Standard Configuration: Instrument, Micro-printer, 200g Sled
Optional Parts: 500g Sled, Non-standard Sled
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
Technical Specifications
| Specifications | COF-01 |
| Capacity Range | 5N (Standard) 10N, 30N, 50N, 100N (Optional) |
| Test Accuracy | 0.1%FS |
| Test Platform Temperature | Room temperature |
| Stroke | 300 mm |
| Sled Mass | 200g (standard), 500g (optional) Customization is available for other masses |
| Test Speed | 100mm/min, 150mm/min 0.05 ~500mm/min (stepless speed regulation) |
| Specimen Height | 0 ~ 30mm |
| Power Supply | AC 220V 50Hz/120V 60Hz |
| Instrument Dimension | 600mm (L)×330 mm (W)×230 mm (H) |
| Net Weight | 35.2 kg |
Standards
ASTM D 1894, ISO 8295, TAPPI T816, GB 10006
Configuration
Standard Configuration: Instrument, Micro-printer, 200g Sled
Optional Parts: 500g Sled, Non-standard Sled
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
