Xenon Lamp Accelerated Weathering Test Chamber

Guangdong Yuanyao Test Equipment Co., Ltd.
  • Certification：CE
  • Warranty：1 Year
  • Inner Chamber Size：600*600*600 mm
  • Temperature Range：Rt~+70 Degrees
  • Humidity Range (Dark)：30%~98%R.H
  • Rainfall Time：1~9999h,59min Adgustable

Base Info

  • Model NO.：YXEL-216
  • Wave Length：200nm~800nm
  • Irradiation Capability：1200W,M2(Adjustable)
  • Irradiance Deviation：+,-0.1 W,M2
  • Temperature and Humidity Sensor：PT100
  • Sample Holder：Automatic Rotary Rack
  • Material：SUS304 Stainless Steel Plate
  • Transport Package：Plywood Case
  • Specification：CE, SGS
  • Trademark：Yunayao
  • Origin：China
  • HS Code：8419899090
  • Production Capacity：100 Sets,Month

Description

YXEL-1000Inner size(W*H*D)mm1000*1000*1000Xenon lamp power(Kw)2.2 KW air cooling type,3.3/4.5KW water cooling typeTemperature rangeRT~+70ºCBlack Panel Temperature40-+80ºCHumidity range (light)10%~70%R.HHumidity range (dark)10%~95%R.HAccuracy rangeTemperature±0.1   humidity±1%R.HRainfall time1~9999h/59min adgustableRainfall cycle1~9999h/59min adgustableWater supply systemBring filter,Automatic control by humidifying water. Cooling water loop xenon lampWave length200nm~800nmIrradiation capability1200W/M2(adjustable)Irradiance deviation±0.1 W/m2Temperature controllerImported weinview color touch screen and PLC control module Siemens GermanyTemperature and humidity sensorPlatinum resistance.PT100Ω/MVSample holderAutomatic rotary rack Materail SUS304 stainless steel plateDoor insulationHigh temperature aging silicone rubber door sealSafety protectionLeakage, short circuit, over temperature, water shortage,
motor overheating, over current protectionTest standardsComplies with JISD0205-1987,GB/T16422.2-1999,ISO4892-2,ASTMG155 GB/T1865-2009 GB/T2423.24-1995 and corresponding standards.Supply voltageAC380V±10% 50±0.5Hz Three phase five wire system Phase
Xenon Lamp Accelerated Weathering Test Chamber

Xenon Lamp Accelerated Weathering Test Chamber
Xenon Lamp Accelerated Weathering Test Chamber
You may also be interested in our other test equipment, any required, please feel free to contact Ms Alice
for offer, thank you for your attention!
Xenon Lamp Accelerated Weathering Test Chamber
