Secondary Injection Relay Test Set & Protective Relay Tester Price

Wuhan Goldhome Hipot Electrical Co., Ltd.
  • After-sales Service：Life Time Support
  • Warranty：1 Year or Extended
  • Type：Strength Testing Machine
  • Accuracy Grade：0.2
  • Display：LCD
  • Weight：15kg

Base Info

  • Model NO.：hmjbc-802
  • Power Source：AC220V
  • Accuracy of Measurement：<0.1ms
  • Phase Voltage / Line Phase Output Power：80va , 100va
  • Harmonic Time：0-20
  • Frequency Range (Fundamental)：0-1000Hz
  • Output Precision：0.5 Degree
  • Time Measuring Range：0.1ms - 9999s
  • Product Name：Relay Tester
  • Transport Package：Wooden Box with Foam Inside
  • Specification：400*360*160mm3
  • Trademark：GDHM
  • Origin：Hubei, China(Mainland)
  • Production Capacity：500sets,Month

Description

Current output              0~±10A / phase,  0~±30A / 3 parallelOutput Precision  0.5 degree

AC voltage output

Phase voltage output (effective value) 0~120V  Output Precision0.2 degreeLine voltage output (effective value)   0~240VPhase voltage / Line phase output power    80VA / 100VAFrequency range (fundamental)                  0~1000HzHarmonic time          0~20

DC voltage output

Phase voltage output range       0~±160V  Output Precision0.5 degreeLine voltage output range     0~±320VPhase voltage / Line phase output power     70VA / 140VA

10 path digital input and 8 path digital output

Time measuring range      0.1ms ~ 9999saccuracy of measurement<0.1msSecondary Injection Relay Test Set & Protective Relay Tester PriceSecondary Injection Relay Test Set & Protective Relay Tester Price
