• Model NO.：XHHD530M
• Certification：CE
• Customized：Customized
• Trademark：XZH TEST
• Origin：China Xi′an
• HS Code：854320100
• Production Capacity：1000 Pieces ,Year

Basic Info.

Model NO. XHHD530M Certification CE Customized Customized Trademark XZH TEST Origin China Xi′an HS Code 854320100 Production Capacity 1000 Pieces /Year

Product Description

cable fault locator



Description

XHLD530M consists of transmitter, receiver, magnetic induction wand, location detection frame and other components, This instrument is a special instrument cable, cable fault location test for the test object is a metal conductor (wire pairs, sheath, shield) of a variety of fiber optic cable. Its main function is to locate bad insulation test points, probe and cable depth testing cable path.



Main features

Higher receiving sensitivity

Lower Static drift

High positioning accuracy

Strong anti-interference capability

LCD display shows the signal and status

Charger and Built-in lithium battery for charging



The Main Technical Parameters

Tracing positioning distance: telephone cable is around 3km, other cables are up to 20km

Positioning impedance range: 0-5MΩ

Positioning accuracy: <± 10cm

Depth probe: <3m

Power supply: DC
